How Does Through Hole Connector Achieve 200k Life Cycles?

Through Hole Connector Delivers 200k Life and IP67 With Tailored Pogo Pins, Ensuring Long-Term Durability and Reliability. Custom Yours Now.

Introduction: The key to ensuring long-term durability is Through Hole Connector

In modern engineering, the durability and IP67 waterproof of through hole connector is often requested by Johoty’s customers. It is used in harsh environments and high-frequency applications. Johoty’s through hole connector is designed with precision customization. It can successfully solve the challenges of traditional connectors in terms of lifespan and environmental adaptability.

Johoty shows you how to connect through hole connector with customized pogo pins. The main goal is to achieve a lifespan of 200,000 cycles and an IP67 waterproof rating. Provide lasting reliability for your engineering projects.

How to achieve a 200k service life for Through hole connector?

In connector design, service life is a key indicator for its reliability. Johoty’s through hole pogo pins connector is a custom-designed pogo pin that achieves a lifespan of 200,000 cycles. This achievement stems from the following technological optimizations.

Firstly, Johoty uses brass, beryllium copper, or stainless steel materials. This ensures the stability and wear resistance of pogo pins during high-frequency insertion and removal processes. Compared to traditional connectors, Johoty’s design reduces contact surface wear. At the same time, we will greatly improve conductivity through surface gold plating processes such as 0.5μm, 1.0μm, and 2.0μm. They can also reduce performance degradation significantly which is caused by corrosion and oxidation.

Secondly, the design of pogo pins takes into account the physical stability under frequent use. We design springs using SWP, SUS631, and other materials to provide stable contact force through hole connector. At the same time, each contact can be precise and effective without any elasticity attenuation. Through this design, Johoty’s through hole pogo pins connector can withstand higher frequencies of use. It is also less prone to poor contact or performance degradation.

Why is IP67 waterproofing crucial for through hole connector?

In many industrial and electronic applications, Johoty’s customers require reliable IP67 waterproofing for their devices. Johoty’s through hole pogo pins connector has an IP67 waterproof and has high performance and stability in extreme environments. IP67 represents complete dust resistance and can keep good function in 1.0m underwater for up to 30 minutes.

In order to meet this standard, Johoty has finely optimized the sealing performance of the through hole pogo pins connector. We use injection molding, 2 or more flange designs, and high-quality rubber seals. We can ensure that the through hole pogo pins connector is not invaded by moisture or dust during use. In addition, the housing design of the through hole connector has been accurately calculated, and all pogo pins can effectively isolate external environmental disturbances. This ensures that through hole pogo pins connector maintains excellent performance and work well in harsh conditions.

How can customized pogo pins improve the performance of through hole connector?

Johoty’s through hole connector can surpass similar products in terms of lifespan and waterproofing. Because it cannot be separated from our customized pogo pins. These customized pogo pins feature our carefully designed spring structure and conductive materials. We can keep high stability, reliability, and durability of through hole pogo pins connector under high-frequency use.

Due to the customized pogo pins springs, customers can maintain consistent contact force during each insertion and removal. It can avoid unstable performance or poor contact caused by uneven contact force. In addition, through customized conductive materials, Johoty’s pogo pins can achieve contact impedance as low as 10mΩ. In this way, the conductivity performance of out through hole pogo pins connector is significantly improved. And, it can still maintain efficient current transmission after long-term use.

Dealing with the challenge of high-frequency use: design of through hole connector

In many engineering applications, the high-frequency use of connectors is an inevitable challenge. Johoty’s precision designed through hole pogo pins connector has successfully addressed this challenge. We often optimize and improve the spring design and contact surface treatment of pogo pins with precision. Johoty can ensure that the through hole connector maintains stable contact performance even after 200,000 uses.

In addition, Johoty has also innovated in the housing material for through hole connector. We use high-strength alloy materials or high-temperature resistant and fire-resistant materials. These materials can effectively withstand the mechanical pressure caused by frequent plugging, avoiding housing deformation or damage. After a series of optimizations, Johoty’s through hole pogo pins connector successfully achieved high-frequency use. In addition, our through hole connector can also maintain excellent mechanical strength as well as electrical performance.

How to solve connection problems in harsh environments with through hole connector?

In high temperature, humid or corrosive environments, traditional connectors often have poor contact, oxidation or corrosion. And Johoty’s through hole pogo pins connector effectively solves these problems through customized pogo pins and optimized sealing design.

Johoty’s through hole connector can withstand high humidity and high salt environments by using antioxidant and corrosion-resistant materials. It can prevent surface degradation caused by environmental factors. The high-strength housing and sealing design can also effectively prevent moisture and dust from entering the through hole pogo pins connector. Ensure that the through hole connector can provide stability, durability, and reliability in various harsh environments.

How to customize through hole connector according to requirements?

The through hole pogo pins connector provided by Johoty is not fixed. We can customize such pogo pin connector according to our clients’ specific needs. This customized service of through hole pogo pin is not limited to pogo pin shape and materials. Johoty can provide various pogo pin connectors on different specifications and sizes according to different applications.

Through in-depth communication with clients, Johoty is able to provide the most suitable connection solution. Ensure that the through hole pogo pins connector achieves optimal performance in specific usage environments. In high temperature, humidity, and corrosive environments, Johoty can provide clients with perfect customized solutions.

Why choose Johoty’s through hole connector?

Choosing Johoty’s through hole connector means choosing a high-quality and highly reliable pogo pin connector. In long-term use, Johoty’s through hole pogo pins connector can provide a lifespan of 200,000 cycles and IP67 waterproofing. We can help customers solve numerous problems they face in practical applications.

Through customized pogo pins, Johoty can provide the most practical connection solution for practical use. Whether it’s high-frequency use or applications in harsh environments, Johoty can provide the best solution. We can ensure that our customers’ equipment always maintains stable performance.

Contact Johoty immediately, through hole connector to help you unlock the future of efficient connectivity

Ensuring the long-term durability and reliability of connectors is crucial in your project. Johoty’s through hole connector features customized pogo pins and innovative design. It successfully solves the problems of traditional connectors in high-frequency use and harsh environments. Contact Johoty now to provide an efficient and reliable through hole connector solution for your project. Enable your device to operate stably in any environment.

Visit the Johoty website immediately to learn more about customized through hole connector solutions. Please contact our professional CFT team. We will tailor the best through hole connector according to your needs to help your project succeed.
