Johoty’s Services of RF Pogo Pin
We are the best technical partner for your project’s early zero tolerance sampling, precise verification, and rapid mass production.
Sample RF Pogo Pin: Fast Response + Free Support for First Round Structural Review
Complete the structural evaluation within 2 days, and provide a sampling plan and confirm the drawings within 3 days. Provide 1-on-1 engineering technology synchronization to ensure zero errors in sample alignment with project progress.
Quality control: aerospace grade standard + micrometer level precision full inspection
Each RF Pogo Pin is CNC machined and laser welded, ensuring a coaxiality of 0.05mm. Fully automatic electrical testing + high-frequency S-parameter detection, with a full inspection rate of 100%.
Delivery commitment: Samples will be produced within 10 days at the earliest, and small batch deliveries will be made within 2 weeks
Samples can be delivered within 2 weeks, and urgent orders can be sampled within 10 days. Batch shipment within 2-3 weeks, minimizing new product development cycle and matching rapid iteration.
MOQ flexible: ≥5pcs samples, supporting customized phased import
Samples can be made with ≥5pcs, supporting gradual evaluation and seamless transition to batch delivery. MOQ3,000pcs, Flexible arrangement and exclusive trial production plan provided. Relieve the initial production pressure of your project and truly start with zero risk.
Logistics method: Global DHL/FedEx direct delivery, 5-8 days delivery to Europe and America
Regular shipping can reach North America and Europe within 5-8 days, supporting the entire export customs declaration process. Provide VIP customer dedicated logistics to meet urgent/bulk concurrent shipment needs.
Contact person qualification: Full English engineering background+10 years of industry experience
1-on-1 docking project manager with practical experience in European and American projects. Proficient in high-frequency connector standards, with independent problem-solving and system integration capabilities. Non-customer service, non-sales, directly connect with people who understand you.
Click: More Catalog
Performance Test of RF Pogo Pin
Signal integrity verification: Supports S-parameter testing up to 10GHz frequency band, with S11 reflection loss<-26dB. High frequency connections have no reflection or interference, comparable to coaxial connections. Specially customized for 5G/millimeter wave/high-precision high-speed board testing.
Durability life test: Through 100000 high-frequency dynamic crimping tests, the contact impedance remains <30mΩ. The connection is stable and has zero drift, suitable for automated testing and repeated high-frequency testing scenarios.
Temperature drift stability test: Contact impedance fluctuation<5% across the entire temperature range of -40℃ to+125℃. Meet the high-temperature stability standards of aerospace, automotive, and military regulations.
Shielding effect detection: >95dB EMI shielding attenuation measurement, ensuring no crosstalk and zero leakage of high-speed RF signals. Tailored RF link integrity verification.
Miniaturization limit verification: The minimum needle shaft diameter is 0.50mm, and consistent impedance matching is maintained under high-density layout. Perfectly supports Mini RF/IoT module/package level testing requirements.
Customized compatibility verification: Supports simulation testing of mainstream interfaces such as SMA, SMP, GSG, GPPO, etc. By using FEM modeling and comparing actual measurement data, ensure the integration and plug and play testing of RF pogo pin docking.
Click: More Catalog
Customization of RF Pogo Pin
Ultra high frequency response: Supports stable transmission from DC to 10GHz, matched with connection structures such as SMA, SMP, GSG, etc. Satisfy millimeter wave, 5G, Wi Fi 6E/7 high-frequency testing and system integration.
Impedance precise customization: 50Ω±10% controllable impedance, stable port S parameters, excellent VSWR performance< 1.15@6GHz , < 1.25@10GHz ）. Ensure that the signal is non reflective and has low loss.
Structural bidirectional design: Double Ended design, supporting double-sided contact or coaxial lead out. Compatible with high-speed testing fixtures, ATE test seats, and RF module docking. Reduce path loss and achieve smaller form factor design.
Exclusive engineering customization: supports customization of pogo pin length, compression stroke, contact resistance, plunger (pointed, ball, concave surface, etc.). 1-on-1 engineering assistance in modeling and simulation, 2-day drawing and 2-week sample submission for lab to mass production.
Consistency guarantee: 100% automated high-frequency testing and screening, full inspection of S11/S21 batches + spectrum archiving. Comparing performance data reveals quality, making engineering decisions with zero guesswork, and ensuring worry free procurement.
Suitable for various applications: compatible with semiconductor testing/communication module verification/high-speed connector simulation/board level RF signal testing, etc. Directly connect with mainstream testing platforms worldwide (Keysight, Rohde&Schwarz, NI, etc.).
Click: More Catalog
FAQ
Can you provide customized size and impedance matching services?
Of course, it supports SMP/MIRCO RF interface customization and precise control of characteristic impedance within 50 Ω± 10%. Provide full link RF simulation design support (HFSS/ADS). Ensure the consistency of structure, electrical, and mechanical dimensions, and shorten the R&D verification cycle.
What high-end applications is this RF Pogo Pin suitable for?
Widely used in Lidar systems, satellite communications, aerospace, high-end medical equipment, and RF module packaging. Meet the triple requirements of high frequency, small size, and high reliability. It is the preferred interface solution for precision connections in high-end industries.
Is there stock available to support sample testing? How long is the delivery time?
The vast majority of them are customized, and different customers have different shapes and parameter requirements. Available in stock specifications, shipped within 1-3 days. Customized items will be shipped within 2 weeks, with a standard bulk delivery cycle of 2-3 days. Provide testing fixtures and performance evaluation reports to assist in accelerating R&D selection and import.
How high frequency can RF pogo pin carry signal transmission?
Supports low loss high-frequency signal transmission up to 10GHz. Suitable for millimeter wave, RF module and high-speed connection solutions. Adapt to 5G RF WiFi 6/7, millimeter wave radar and high-speed interconnection. No additional shielding structure is required, and the signal integrity is stable.
Does the RF pogo pin have high repeat contact reliability?
Over 10,000 stable crimping cycles, contact impedance <50mΩ, ensuring long-term high reliability communication. Adopting a customized alloy pogo pin material and gold coating, the contact performance has been verified by authoritative laboratories and is suitable for automated repeated docking testing.
